Huixian city Xinda Textile Machinery Accessories Co., Ltd. provides E-6-104 Loom Tools Shuttle Magazine Height,textile hardware and tools -1511M-E-6-104 loom to gauge the height of shuttle box, raise back plate and control wood tools. Its main uses can be divided into four points: 1. 1511M-N16, N17 (shuttle box foot) plane and 1515-3308 (shuttle box bottom plate 1511-K15). 2. The vertical distance between the bottom surfaces (1515-3312, Q7) of GA615-2106 and 2111(Q6 raises the backboard) and the plane of 1515-3308 is 9mm;

3. The parallel distance between the front face of 1515-3311(1511-Q17) and the rear face of 1515-3314 is 89mm；; 4. The height distance between the lower surface of 1515-3311(Q17 control wood) and the plane of 1515-3308 is 13 mm.1515 Loom Tools,GA615 Shuttle Magazine Tools,Textile Tools,Regulation.

The gauge of 1511M-E-6-104 shuttle magazine has a total length of 190.7mm, a total width of 16mm, a front width of 13mm and a total thickness of 9mm；. The depth of the front notch is 5mm and the inner length is 20 mm.

The thickness of the front four squares of the loom maintenance tool -6-104 is 7.5mm, the width is 10mm and the length is 13mm；; The length from the tail of the gauge to the step is 89.5 mm. 1511M-E-6-104 Loom's fixed shuttle magazine is mainly used for fully automatic shuttle changing looms, including models 1511, 1515, GA611 and GA615.

The weight of a single 6-104 shed gauge is 179 g -181 g; For more information about parameters and materials of this gauge, please contact Yang Jingli of our company for consultation. We sincerely welcome your presence and guidance.
